• Rating：12VDC 50mA
• Travel：0.13mm
• Life：100,000~300,000 cycles
• Contact Resistance：100mΩ MAX Initial
• Insulation Resistance：100mΩ min. 100VDC
• Dielectric Strength：250VAC(50/60Hz)FOR 1MIN
• Operating Force：A=180gf B=260gf
• Operating Temperature：-30℃ ~80℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Travel | Life | Operating Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| RTPA-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPB-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPU-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPS-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPF-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPML-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPMP-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPMN-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| RTPMU-A/B-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | A=180gf B=260gf | 0.13mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
