• Rating：12VDC 50mA
• Travel：0.2mm
• Life：100,000 cycles
• Contact Resistance：100mΩ MAX Initial
• Insulation Resistance ：100mΩ min. 100VDC
• Dielectric Strength：250VAC(50/60Hz)FOR 1MIN
• Operating Force：2=180gf 3=260gf
• Operating Temperature：-30℃ ~70℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Travel | Life | Operating Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R1023-C-2/3-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.2mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
| R1023-35-2/3-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.2mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
| R1023-60-2/3-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.2mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
| R1023-2-2/3-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.2mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
| R1023-2-180-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.2mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
